A929 48V 100Ah
|
Items
|
TP-A987-48V/100Ah 50A 2400W
|
|
Nominal voltage (V)
|
48V
|
|
Nominal capacity (Ah)
|
100Ah
|
|
Rated energy(Wh)
|
4800Wh（4.8KWh）
|
|
Maximum charging voltage(V)
|
54.75V
|
|
Maximum charging current(A)
|
50A
|
|
Maximum continuous discharge current (A)
|
50A
|
|
Maximum peak discharge current@30seconds(A)
|
100A
|
|
Maximum load power (W)
|
2400W
|
|
Discharge cut-off voltage (V)
|
33V
|
|
Cell model
|
LF100LA
|
|
Battery brand
|
Yiwei
|
|
Cell combination method
|
15S1P
|
|
Cycle (25°C.0.5C,DOD80%)
|
5000
|
|
Protection class
|
IP65
|
|
Overall dimensions (mm)
|
908*190*170mm
|
|
Reference weight (kg)
|
About 41.3kg
|
|
Application areas
|
AGV, handling trolley
|
|
Charging temperature(°C)
|
0~65℃
|
|
Discharge temperature(°C)
|
-20℃~55℃
|
|
Communication model
|
RS485
|
